Thông số kỹ thuật
Thông số kỹ thuật
| System parameters | |
| Processor | Embedded MCU Processor |
| Operation method | Physical button |
| Interfaces | |
| Module connecting | 2 (1 input, 1 output) |
| Debug | 1 |
| General | |
| Physical button | 12 |
| DIP switch | 8 |
| Power input | 12 VDC (powered by the other module) |
| Power output | 12 VDC (powered for the other module) |
| Power consumption | 1 W |
| Working temperature | -40° C to +55° C(-40° F to 131° F) |
| Working humidity | 10% to 95% |
| IP protection level | IP65, IK7 |
| Installation | Flush mounting, surface mounting |
| Dimension | 98.5 mm × 100 mm × 34.2 mm |
| Weight | 529 g (with packaging) 265 g (without packaging) |
