Thông số kỹ thuật
Thông số kỹ thuật
| Model | IPC-HFW2231TP-ZS-S2 |
| Camera | |
| Image Sensor | 1/2.8 inch CMOS |
| Effective Pixels | 1920(H) x 1080(V) |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3s – 1/100000 s |
| Minimum Illumination | 0.002 Lux @F1.6 |
| IR Distance | 50m |
| IR On/Off Control | Auto / Manual |
| IR LEDs | 4 |
| Pan/Tilt Range | Pan: 0°~360°; Tilt: 0°~90°; Rotation: 0°~360° |
| Lens | |
| Lens Type | Motorized vari-focal |
| Mount Type | φ14 |
| Focal Length | 2.7 mm–13.5 mm |
| Max Aperture | F1.6 |
| Field of View | Horizonal: 109°–28° Vertical: 57°–16° Diagonal: 131°–33° |
| Optical Zoom | 5x |
| Iris Type | Fixed aperture |
| Smart event | |
| General IVS Analytics | Tripwire; intrusion |
| Video | |
| Compression | H.265; H.264; H.264B; MJPEG |
| Streaming Capability | Main stream; sub stream |
| Day/Night | ICR switch |
| BLC Mode | Yes |
| WDR | 120dB |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D DNR |
| White Balance | Auto/ natural/ street lamp/ outdoor/ manual/ regional custom |
| Motion Detetion | Off / On (4 Zone, Rectangle) |
| Region of Interest | Yes (4 areas) |
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 1080p resolution.) |
| Mirror | Yes |
| Privacy Masking | 4 areas |
| Network | |
| Ethernet | RJ-45 (10/100Base-T) |
| Protocol | HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPoE; IPv4/v6; QoS; UPnP; NTP; RTMP; Multicast; HTTPS; SFTP; 802.1x; ICMP; IGMP |
| Interoperability | ONVIF (Profile S/Profile G); CGI; Milestone; Genetec |
| User/Host | 20 |
| Edge Storage | Dahua Cloud; FTP; Micro SD Card (support max. 256 GB); NFS |
| Management Software | Smart PSS; DSS; DMSS |
| Others | |
| Power Supply | 12VDC/PoE |
| Protection Grade | IP67 |
| Casing | Metal |
| Dimensions | Φ244.1 × 90.4 mm |
| Weight | 0.86kg |
