| Camera |
| Image Sensor |
1/2.8″ Progressive Scan CMOS |
| Min. Illumination |
Color: |
| 0.025 Lux @(F1.2; AGC ON) |
| 0.07 Lux @(F2.0; AGC ON) |
| 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Slow Shutter |
Support |
| Lens |
2.8 mm: horizontal FOV: 114°, vertical FOV: 62°, diagonal FOV: 135° |
| 4 mm: horizontal FOV: 86°, vertical FOV: 46°, diagonal FOV: 102° |
| 6 mm: horizontal FOV: 54°, vertical FOV: 30°, diagonal FOV: 62° |
| Lens Mount |
M12 |
| Aperture |
F2.0 |
| Day &Night |
IR cut filter |
| DNR |
3D DNR |
| Wide Dynamic Range |
DWDR |
| 3-Axis Adjustment |
Pan: 0° to 355° , tilt: 0° to 70° |
| Compression Standard |
| Video Compression |
Main stream: H.265/H.264 |
| Sub stream: H.265/H.264/MJPEG |
| H.264 Type |
Main Profile/High Profile |
| H.264+ |
Support |
| H.265 Type |
Main Profile |
| H.265+ |
Support |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| Audio Compression (-S) |
G.711/G.722.1/G.726/MP2L2 |
| Audio Bit Rate (-S) |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-128Kbps(MP2L2) |
| Image |
| Max. Resolution |
1920 × 1080 |
| Main Stream |
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280×720) |
| 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280×720) |
| Sub Stream |
50Hz: 25fps (640 × 360, 352 × 288) |
| 60Hz: 30fps (640 × 360, 352 × 240) |
| Image Enhancement |
BLC/3D DNR |
| Image Settings |
Support rotate mode. Brightness, contrast, saturation, and sharpness are adjustable via web browser and client software |
| Day/Night Switch |
Auto/Scheduled/Alarm Triggered |
| Audio |
| Environment Noise Filtering |
Support |
| Audio I/O |
Support |
| Sampling Rate |
Max. 48kHz |
| Network |
| Network Storage |
Support microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Alarm Trigger |
Motion Detection, Tampering Alarm, Network Disconnected, IP Address Conflict, Illegal Login, HDD full, HDD error |
| Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6 |
| Standard |
ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
| General Function |
One-key Reset , Anti-Flicker, Heartbeat, Mirror, Password Protection, Privacy Mask, Watermark, IP Address Filter |
| Interface |
| Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| Audio |
1 audio input (line in), 1 audio output interface |
| Alarm |
1 alarm input, 1 alarm output |
| On-board Storage |
Built-in microSD/SDHC/SDXC slot, up to 128 GB |
| General |
| Operating Conditions |
-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing) |
| Power Supply |
DC 12V ± 25%, 6W |
| IR Range |
Up to 30 m |
| Protection Level |
IP67, IK10 |
| Material |
Metal&plastic |
| Dimensions |
Φ 111 × 82.4 mm (Φ 4.4″ × 3.2″) |
| Weight |
500 g (1.1 lb.) |
